Main spec

 Sawblade outside dia.

 Ø100 ~ Ø810 mm/ 4" ~ 32"

 Bore of sawblade

 Ø10 ~ Ø120 mm

 Sawblade thickness

 Up 8 mm

 Tooth Pitch

 8 ~ 70 mm

 Grinding wheel outside dia.

 Ø125 mm

 Bore of grinding wheel

 Ø32 mm

 Grinding speed

 0.5 ~ 10 mm/s

 Teeth pushing speed

 20 Teeth/min

 Grind wheel speed

 4200 R.P.M.

 Motors

 Grinding wheel motor

 1 HP

 Wheel feed motor (stepping motor)

 0.3 kw

 Wheel head R/L swiveling motor (servo motor)

 0.75 kw

 Hydraulic motor

 2 HP

 Coolant pump motor

 0.17 kw

 Tooth angles

 Bevel grinding at the tooth top

 0° to 45°

 Bevel grinding at the tooth face

 0° to 30°

 Clearance angle

 5° to 45°

 Rake or Hook angle

 0° to 40°
